DM 300 AP ELEFANTINO

Tripod hoists

Due to shape and lifting capacity, this hoist is indispensable in some conditions. It must be completed with its own tripod pole.

Techinical data
  DM 300 AP ELEFANTINO
Safe working load kg 300
Weight of the hoist kg 70
Lifting speed m/min 21
Electric motor single-phase
Power kW 1,45
Current intensity A 8
Voltage V 230
Frequency Hz 50
Rotor shaft angular speed rpm 1400
Reduction ratio 1:25,5
Ø non-rotating wire rope mm 5
Breaking load kN 17
Lenght of the rope m 25
Max lenght of the rope m 40
Lenght 760
Width 350
Height 630
